| Deublin Part Number | Supply Connection | Rotor Connection | Overall Length | Housing Diameter | Maximum Pressure and Media | Maximum Speed | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
655-823-832 | G 2"-11 | G 2"-11 RH | 117.5 mm | 4.626" |
6.9 bar Hot Oil 1 bar Steam 13.8 bar Water |
100 PSI Hot Oil 15 PSI Steam 200 PSI Water |
750 RPM | |||
|
655-500-116013 | 2"-11.5 NPT RH | 750 RPM | ||||||||
|
1109-020-188 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 53.5 mm | 2.106" |
103.4 bar Coolant 10 bar MQL |
1500 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
|
1114-010-165 | 5/8"-18 UNF LH, 16.65 mm pilot | 5/8"-18 UNF LH, 0.656" pilot | ||||||||
|
|
1114-011-165 | 5/8"-18 UNF LH, 16.649 mm pilot | 5/8"-18 UNF LH, 0.655" pilot | 53.5 mm | 2.106" |
10 bar Air 103.4 bar Coolant 10 bar MQL |
150 PSI Air 1500 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
|
1114-040-188 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 53.5 mm | 2.106" |
10 bar Air 103.4 bar Coolant 10 bar MQL |
150 PSI Air 1500 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
|
1114-020-192 | M16x1.5 LH, 16.025 mm pilot | M16x1.5 LH, 0.631" pilot | 53.5 mm | 2.106" |
10 bar Air 103.4 bar Coolant 10 bar MQL |
150 PSI Air 1500 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
1114-021-188 | G 3/8"-19 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 132 mm | 5.197" | |||||
|
1114-020-188 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 53.5 mm | 2.106" |
10 bar Air 103.4 bar Coolant 10 bar MQL |
150 PSI Air 1500 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
|
1109-011-164 | 3/8"-18 NPT | 5/8"-18 UNF RH, 16.649 mm pilot | 5/8"-18 UNF RH, 0.655" pilot | 53.5 mm | 2.106" |
103.4 bar Coolant 10 bar MQL |
1500 PSI Coolant 150 PSI MQL |
20000 RPM | ||
|
|
1109-760-188 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 53.5 mm | 2.106" |
69 bar Coolant |
1000 PSI Coolant |
15000 RPM | |||
|
|
1109-024-212 | G 1/4"-19 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 129 mm | 5.079" | 53.5 mm | 2.106" |
140 bar Coolant 10 bar MQL |
2030 PSI Coolant 150 PSI MQL |
20000 RPM |
|
1109-041-192 | M16x1.5 LH, 16.025 mm pilot | M16x1.5 LH, 0.631" pilot | 53.5 mm | 2.106" |
103.4 bar Coolant 10 bar MQL |
1500 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
|
1109-071-480 | M16x1.5 LH, 17.994 mm pilot | M16x1.5 LH, 0.708" pilot | 53.5 mm | 2.106" |
140 bar Coolant 10 bar MQL |
2030 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
1109-010-165 | 5/8"-18 UNF LH, 16.649 mm pilot | 5/8"-18 UNF LH, 0.655" pilot | 53.5 mm | 2.106" |
103.4 bar Coolant 10 bar MQL |
1500 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
1109-040-388 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 53.5 mm | 2.106" |
103.4 bar Coolant 10 bar MQL |
1500 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
1109-040-188RW | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 53.5 mm | 2.106" |
103.4 bar Coolant 10 bar MQL |
1500 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
|
1109-011-192 | M16x1.5 LH, 16.025 mm pilot | M16x1.5 LH, 0.631" pilot | 53.5 mm | 2.094" |
103.4 bar Coolant 10 bar MQL |
1500 PSI Coolant 150 PSI MQL |
20000 RPM | |||
|
1109-044-412 | 1/4"-19 PT | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 124 mm | 4.882" | |||||
|
|
1109-011-188 | 3/8"-18 NPT | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 53.5 mm | 2.106" |
103.4 bar Coolant 10 bar MQL |
1500 PSI Coolant 150 PSI MQL |
20000 RPM |
