| Features.ProductSeries.DeublinPartNumberDisplay | Features.ProductSeries.SupplyConnectionDisplay | Features.ProductSeries.RotorConnectionDisplay | Features.ProductSeries.OverallLengthDisplay | Features.ProductSeries.HousignDiameterDisplay | Features.ProductSeries.MaxPressureDisplay | Features.ProductSeries.MaxSpeedDisplay | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
21-040-101 | 3/4"-14 NPT RH | |||||||||
|
9210-002-104 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | ||||||||
|
452-000-395 | 2"-12 UN RH | 107.95 mm | 4.25" |
10 bar Luft 51.7 bar Hydrauliköl -0.95 bar Vakuum |
150 PSI Luft 750 PSI Hydrauliköl -13.75 PSI Vakuum |
2500 RPM | ||||
|
|
452-000-198 | G 1-1/2"-11 RH | 108 mm | 4.252" |
10 bar Luft 51.7 bar Hydrauliköl -0.95 bar Vakuum |
150 PSI Luft 750 PSI Hydrauliköl -13.75 PSI Vakuum |
2500 RPM | ||||
|
1102-070-166 | 35 mm Flange, 30.026 mm pilot | 1.378" Flange, 1.182" pilot | 3500 RPM | |||||||
|
1102-025-001004 | 1/4"-18 NPT RH, 25.3 mm pilot | 1/4"-18 NPT RH, 0.996" pilot | 63.75 mm | 2.51" |
10 bar Luft 69 bar Hydrauliköl -0.95 bar Vakuum |
150 PSI Luft 1000 PSI Hydrauliköl -13.75 PSI Vakuum |
3500 RPM | |||
|
1102-070-121 | 5/8"-18 UNF RH, 16.65 mm pilot | 5/8"-18 UNF RH, 0.656" pilot | 41.07 mm | 1.617" |
10 bar Luft 69 bar Hydrauliköl -0.95 bar Vakuum |
150 PSI Luft 1000 PSI Hydrauliköl -13.75 PSI Vakuum |
3500 RPM | |||
|
1102-208-210 | 1/4"-18 NPT | 5/8"-18 UNF RH | 81 mm | 3.189" | ||||||
|
|
1102-070-079 | 5/8"-18 UNF LH | 41.3 mm | 1.626" |
10 bar Luft 69 bar Hydrauliköl -0.95 bar Vakuum |
150 PSI Luft 1000 PSI Hydrauliköl -13.75 PSI Vakuum |
3500 RPM | ||||
|
1102-292-291 | M12x1.75 Female RH, 14.026 mm pilot | M12x1.75 Female RH, 0.552" pilot | 40.7 mm | 1.602" |
10 bar Luft 69 bar Hydrauliköl -0.95 bar Vakuum |
150 PSI Luft 1000 PSI Hydrauliköl -13.75 PSI Vakuum |
3500 RPM | |||
|
1129-470-120 | M30x1.5 RH, 32 mm pilot | M30x1.5 RH, 1.26" pilot | 76 mm | 2.992" |
140 bar Kühlmittel |
2030 PSI Kühlmittel |
||||
|
1129-927-929 | M14x1.5 LH, 14.494 mm pilot | M14x1.5 LH, 0.571" pilot | 54 mm | 2.126" |
150 bar Kühlmittel 150 bar Schneidöl 10 bar Minimalmengenschmierung (MMS) |
2175 PSI Kühlmittel 2175 PSI Schneidöl 150 PSI Minimalmengenschmierung (MMS) |
30000 RPM | |||
|
1129-584 | O-ring, 12 mm pilot | O-ring, 0.472" pilot | ||||||||
|
1129-718-480 | M16x1.5 LH, 17.993 mm pilot | M16x1.5 LH, 0.708" pilot | 53 mm | 2.087" |
140 bar Kühlmittel 10 bar Minimalmengenschmierung (MMS) |
2030 PSI Kühlmittel 150 PSI Minimalmengenschmierung (MMS) |
20000 RPM | |||
|
|
1690-000-105 | G 1"-11 RH | 66.4 mm | 2.614" |
10 bar Luft 207 bar Hydrauliköl -0.95 bar Vakuum |
150 PSI Luft 3000 PSI Hydrauliköl -13.75 PSI Vakuum |
250 RPM | ||||
|
1690-000-115 | 1"-11.5 NPT RH | 66.6 mm | 2.622" |
10 bar Luft 207 bar Hydrauliköl -0.95 bar Vakuum |
150 PSI Luft 3000 PSI Hydrauliköl -13.75 PSI Vakuum |
250 RPM | ||||
|
|
1690-000-102 | 1/4"-18 NPT | 1"-11.5 NPT RH | 66.6 mm | 2.622" |
10 bar Luft 207 bar Hydrauliköl -0.95 bar Vakuum |
150 PSI Luft 3000 PSI Hydrauliköl -13.75 PSI Vakuum |
250 RPM | |||
|
1690-000-168 | G 1"-11 RH | |||||||||
|
|
2620-001-252 | 107.95 mm Flange, 107.95 mm pilot | 4.25" Flange, 0.75" pilot | 63 mm | 2.48" |
100 bar Hydrauliköl 30 bar Hydrauliköl |
1450 PSI Hydrauliköl 435 PSI Hydrauliköl |
7000 RPM | |||
|
2620-040-157 | 80.985 mm Flange, 81 mm pilot | 3.188" Flange, 3.19" pilot | 60 mm | 2.362" |
100 bar Hydrauliköl 30 bar Hydrauliköl |
1450 PSI Hydrauliköl 435 PSI Hydrauliköl |
12000 RPM |
