| Deublin Part Number | Supply Connection | Rotor Connection | Overall Length | Housing Diameter | Maximum Pressure and Media | Maximum Speed | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
557-050-002 | 1-1/2"-11.5 NPT | 1-1/2"-11.5 NPT LH | 216 mm | 8.504" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
1500 RPM | |
|
557-000-395 | 1-1/2"-11.5 NPT | 2"-12 UN RH | 225 mm | 8.858" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM | |
|
|
557-134-495144 | 3/4"-14 NPT | 120 mm Flange, 49.7 mm pilot | 4.724" Flange, 1.957" pilot | 247 mm | 9.724" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
1000 RPM |
|
|
557-000-201 | 1-1/2"-11.5 NPT | M50x1.5 LH | 222 mm | 8.74" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM | |
|
|
557-000-198013 | 1-1/2"-11.5 NPT | G 1-1/2"-11 RH | 270 mm | 10.63" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
1000 RPM | |
|
|
557-000-765467 | 1-1/2"-11.5 NPT | 99.82 mm Flange, 64.77 mm pilot | 3.93" Flange, 2.55" pilot | 264.8 mm | 10.425" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM |
|
557-130-199 | G 1-1/2"-11 | G 1-1/2"-11 LH | 228 mm | 8.976" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM | |
|
|
557-000-396 | 1-1/2"-11.5 NPT | 2"-12 UN LH | 225 mm | 8.858" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM | |
|
|
558-051-077 | 1-1/2"-11.5 NPT | 1-1/2"-11.5 NPT RH | 217 mm | 8.543" | 108.4 mm | 4.268" |
10 bar Water |
150 PSI Water |
1500 RPM | |
|
557-050-001 | 1-1/2"-11.5 NPT | 1-1/2"-11.5 NPT RH | 215 mm | 8.465" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
1500 RPM | |
|
|
557-050-396144 | 1-1/2"-11.5 NPT | 2"-12 UN LH | 219 mm | 8.622" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM | |
|
557-130-198 | G 1-1/2"-11 | G 1-1/2"-11 RH | 232.5 mm | 9.154" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM | |
|
|
557-050-001013 | 1-1/2"-11.5 NPT | 1-1/2"-11.5 NPT RH | 262 mm | 10.315" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
1000 RPM | |
|
557-050-198 | 1-1/2"-11.5 NPT | G 1-1/2"-11 RH | 226.2632 mm | 8.908" | 107.95 mm | 4.25" |
10 bar Water |
150 PSI Water |
2500 RPM | |
|
557-000-198 | 1-1/2"-11.5 NPT | G 1-1/2"-11 RH | 228 mm | 8.976" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM | |
|
|
557-050-395 | 1-1/2"-11.5 NPT | 2"-12 UN RH | 255 mm | 10.039" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM | |
|
557-000-002 | 1-1/2"-11.5 NPT | 1-1/2"-11.5 NPT LH | 215 mm | 8.465" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
1500 RPM | |
|
|
557-000-001166 | 1-1/2"-11.5 NPT | 1-1/2"-11.5 NPT RH | 276 mm | 10.866" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
1000 RPM | |
|
|
557-000-222 | 1-1/2"-11.5 NPT | M50x1.5 LH | 219 mm | 8.622" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM | |
|
557-000-200 | 1-1/2"-11.5 NPT | M50x1.5 RH | 226.5 mm | 8.917" | 108 mm | 4.252" |
10 bar Water |
150 PSI Water |
2500 RPM |
