| Número de pieza de Deublin | Conexión de suministro | Conexión del rotor | Longitud total | Diámetro de la carcasa | Presión y medios máximos | Velocidad máxima | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
6200-044-137 | 2"-11.5 NPT | G 2"-11 RH | 211.1 mm | 8.311" | 133.4 mm | 5.252" |
10 bar Agua |
150 PSI Agua |
750 RPM | |
|
|
6200-044-137 | 2"-11.5 NPT | G 2"-11 RH | 211.1 mm | 8.311" | 133.4 mm | 5.252" |
10 bar Agua |
150 PSI Agua |
750 RPM | |
|
6200-001-137 | G 2"-11 RH | 290 mm | 11.417" | 133 mm | 5.236" |
10 bar Agua |
150 PSI Agua |
750 RPM | ||
|
|
6200-001-137 | G 2"-11 RH | 290 mm | 11.417" | 133 mm | 5.236" |
10 bar Agua |
150 PSI Agua |
750 RPM | ||
|
|
6200-083-137 | 1"-11.5 NPT | G 2"-11 RH | 324.5 mm | 12.776" | 133.4 mm | 5.252" |
10 bar Agua |
150 PSI Agua |
750 RPM | |
|
|
6200-083-137 | 1"-11.5 NPT | G 2"-11 RH | 324.5 mm | 12.776" | 133.4 mm | 5.252" |
10 bar Agua |
150 PSI Agua |
750 RPM | |
|
|
6200-030-123 | 1"-11.5 NPT | 2"-11.5 NPT RH | 326 mm | 12.835" | 133.4 mm | 5.252" |
10 bar Agua |
150 PSI Agua |
750 RPM | |
|
|
6200-030-123 | 1"-11.5 NPT | 2"-11.5 NPT RH | 326 mm | 12.835" | 133.4 mm | 5.252" |
10 bar Agua |
150 PSI Agua |
750 RPM | |
|
|
6200-002-137 | 1"-11.5 NPT | G 2"-11 RH | 317 mm | 12.48" | 133 mm | 5.236" |
10 bar Agua |
150 PSI Agua |
750 RPM | |
|
|
6200-002-137 | 1"-11.5 NPT | G 2"-11 RH | 317 mm | 12.48" | 133 mm | 5.236" |
10 bar Agua |
150 PSI Agua |
750 RPM | |
|
|
6300-001-103 | 3"-8 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 430 mm | 16.929" | 229 mm | 9.016" |
10 bar Agua |
150 PSI Agua |
750 RPM |
|
|
6300-001-103 | 3"-8 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 430 mm | 16.929" | 229 mm | 9.016" |
10 bar Agua |
150 PSI Agua |
750 RPM |
|
|
6300-051-161 | 3"-8 NPT | G 3"-11 RH | 325 mm | 12.795" | 230 mm | 9.055" |
10 bar Agua |
150 PSI Agua |
750 RPM | |
|
|
6300-607-103 | 2"-11.5 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 499.4 mm | 19.661" | 228.6 mm | 9" |
10 bar Agua |
150 PSI Agua |
750 RPM |
|
|
6300-030-103 | 2"-11.5 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 499 mm | 19.646" | 229 mm | 9.016" |
10 bar Agua |
150 PSI Agua |
750 RPM |
|
|
6300-051-161 | 3"-8 NPT | G 3"-11 RH | 325 mm | 12.795" | 230 mm | 9.055" |
10 bar Agua |
150 PSI Agua |
750 RPM | |
|
|
6300-607-103 | 2"-11.5 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 499.4 mm | 19.661" | 228.6 mm | 9" |
10 bar Agua |
150 PSI Agua |
750 RPM |
|
|
6300-030-103 | 2"-11.5 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 499 mm | 19.646" | 229 mm | 9.016" |
10 bar Agua |
150 PSI Agua |
750 RPM |
|
|
6300-002-103 | 2"-11.5 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 505.5 mm | 19.902" | 229 mm | 9.016" |
10 bar Agua |
150 PSI Agua |
750 RPM |
|
|
6300-002-103 | 2"-11.5 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 505.5 mm | 19.902" | 229 mm | 9.016" |
10 bar Agua |
150 PSI Agua |
750 RPM |
