| Deublin Part Number | Supply Connection | Rotor Connection | Overall Length | Housing Diameter | Maximum Pressure and Media | Maximum Speed | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
157-000-738 | 1/2"-14 NPT | M20x1.5 RH, 21.987 mm pilot | M20x1.5 RH, 0.866" pilot | 124 mm | 4.882" | 57.2 mm | 2.252" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM |
|
|
157-1012-151 | G 3/8"-19 | G 1/2"-14 RH | 115 mm | 4.528" | 57.2 mm | 2.252" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | |
|
|
157-1005-151 | 1/2"-14 NPT | G 1/2"-14 RH | 116.92 mm | 4.603" | 57.2 mm | 2.252" |
6.2 bar Hot Oil 1 bar Steam 51.7 bar Water |
90 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | |
|
|
157-1007-151 | G 1/2"-14 | G 1/2"-14 RH | 119 mm | 4.685" | 57.2 mm | 2.252" |
6.2 bar Hot Oil 1 bar Steam 51.7 bar Water |
90 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | |
|
|
157-2003-001 | 1/2"-14 NPT | 1/2"-14 NPT RH | 122 mm | 4.803" | 57.2 mm | 2.252" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
1500 RPM | |
|
|
157-2001-151199 | 1/2"-14 NPT | G 1/2"-14 RH | 145.1 mm | 5.713" | 57.2 mm | 2.252" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | |
|
|
157-2311-151199 | 1/2"-14 NPT | G 1/2"-14 RH | 141.25 mm | 5.561" | 57.2 mm | 2.252" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | |
|
|
157-027-151 | G 1/2"-14 RH | 120 mm | 4.724" | 57.2 mm | 2.252" |
10 bar Water 6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
150 PSI Water 100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | ||
|
157-028-125 | G 3/8"-19 | G 1/2"-14 RH | 118 mm | 4.646" | 57.2 mm | 2.252" |
10 bar Water |
150 PSI Water |
3500 RPM | |
|
157-000-001012 | 1/2"-14 NPT | 1/2"-14 NPT RH | 151 mm | 5.945" | 57.2 mm | 2.252" |
10 bar Water 6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
150 PSI Water 100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
1500 RPM | |
|
157-410-404 | G 3/8"-19 | G 1/2"-14 RH, 20.993 mm pilot | G 1/2"-14 RH, 0.826" pilot | 107.4 mm | 4.228" | 57.2 mm | 2.252" |
10 bar Water |
150 PSI Water |
3500 RPM |
|
|
157-006-021 | 1/2"-14 NPT | 3/4"-16 UNF RH | 119.3 mm | 4.697" | 57.2 mm | 2.252" |
10 bar Water 6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
150 PSI Water 100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | |
|
157-326-342168 | G 3/8"-19 | G 1/2"-14 RH | 150 mm | 5.906" | 57.2 mm | 2.252" |
10 bar Water |
150 PSI Water |
3500 RPM | |
|
157-508-201 | G 3/8"-19 | M20x1.5 RH, 20.003 mm pilot | M20x1.5 RH, 0.788" pilot | 113 mm | 4.449" | 57.2 mm | 2.252" |
10 bar Water |
150 PSI Water |
3500 RPM |
|
|
157-050-021061 | 1/2"-14 NPT | 3/4"-16 UNF RH | 150 mm | 5.906" | 57.2 mm | 2.252" |
10 bar Water 6.2 bar Hot Oil 1 bar Steam 51.7 bar Water |
150 PSI Water 90 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | |
|
157-400-201 | G 3/8"-19 | M20x1.5 RH, 20.993 mm pilot | M20x1.5 RH, 0.826" pilot | 111 mm | 4.37" | 57.2 mm | 2.252" |
10 bar Water |
150 PSI Water |
3500 RPM |
|
157-000-021 | 1/2"-14 NPT | 3/4"-16 UNF RH | 119 mm | 4.685" | 57.2 mm | 2.252" |
10 bar Water 6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
150 PSI Water 100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | |
|
|
157-2003-002 | 1/2"-14 NPT | 1/2"-14 NPT LH | 122 mm | 4.803" | 57.2 mm | 2.252" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
1500 RPM | |
|
|
157-2003-151 | 1/2"-14 NPT | G 1/2"-14 RH | 121.9 mm | 4.799" | 57.2 mm | 2.252" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | |
|
|
157-2022-001 | 1/2"-14 NPT | 1/2"-14 NPT RH | 122.3 mm | 4.815" | 57.2 mm | 2.252" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
1500 RPM |
