Product Selector

Many more designs are available. For assistance, contact Deublin Customer Service at +1-847-689-8660 or cs@deublin.com.

Imperial Metric
Filter By:

9 results out of 20,000+ available products.

Swipe for more
Deublin Part Number Supply Connection Rotor Connection Overall Length Housing Diameter Maximum Pressure and Media Speed
1890-110 3/4"-14 NPT 1-1/2"-11.5 NPT RH 225 mm 8.858" 88.3 mm 3.476"

10 bar Air

207 bar Hydraulic Oil

-0.95 bar Vacuum

150 PSI Air

3000 PSI Hydraulic Oil

-13.75 PSI Vacuum

250 RPM
1890-063 3/4"-14 NPT G 1-1/2"-11 RH 225.4 mm 8.874" 88.3 mm 3.476"

10 bar Air

207 bar Hydraulic Oil

-0.95 bar Vacuum

150 PSI Air

3000 PSI Hydraulic Oil

-13.75 PSI Vacuum

250 RPM
1890-100 3/4"-14 NPT 1-1/2"-11.5 NPT RH 225 mm 8.858" 88.4 mm 3.48"

10 bar Air

207 bar Hydraulic Oil

-0.95 bar Vacuum

150 PSI Air

3000 PSI Hydraulic Oil

-13.75 PSI Vacuum

250 RPM
1890-500 3/4"-14 NPT 1-1/2"-11.5 NPT RH 225.4 mm 8.874" 88.3 mm 3.476"

10 bar Air

207 bar Hydraulic Oil

-0.95 bar Vacuum

150 PSI Air

3000 PSI Hydraulic Oil

-13.75 PSI Vacuum

250 RPM
1890-560 3/4"-14 NPT G 1-1/2"-11 RH 225.4 mm 8.874" 87.63 mm 3.45"

10 bar Air

207 bar Hydraulic Oil

-0.95 bar Vacuum

150 PSI Air

3000 PSI Hydraulic Oil

-13.75 PSI Vacuum

250 RPM
1890-060 3/4"-14 NPT G 1-1/2"-11 RH 225 mm 8.858" 88.5 mm 3.484"

10 bar Air

207 bar Hydraulic Oil

-0.95 bar Vacuum

150 PSI Air

3000 PSI Hydraulic Oil

-13.75 PSI Vacuum

250 RPM
1890-260 3/4"-14 NPT 1-1/2"-11.5 NPT RH 225 mm 8.858" 88.4 mm 3.48"

10 bar Air

207 bar Hydraulic Oil

-0.95 bar Vacuum

150 PSI Air

3000 PSI Hydraulic Oil

-13.75 PSI Vacuum

250 RPM
1890-262 3/4"-14 NPT 1-1/2"-11.5 NPT RH 229 mm 9.016" 93 mm 3.661"

10 bar Air

207 bar Hydraulic Oil

-0.95 bar Vacuum

150 PSI Air

3000 PSI Hydraulic Oil

-13.75 PSI Vacuum

250 RPM
1890-279 3/4"-14 NPT 1-1/2"-11.5 NPT RH 225 mm 8.858" 89 mm 3.504"

10 bar Air

207 bar Hydraulic Oil

-0.95 bar Vacuum

150 PSI Air

3000 PSI Hydraulic Oil

-13.75 PSI Vacuum

250 RPM
Page 1 of 1
