Product Selector

Many more designs are available. For assistance, contact Deublin Customer Service at +1-847-689-8660 or cs@deublin.com.

Imperial Metric
Filter By:

86 results out of 20,000+ available products.

Swipe for more
Deublin Part Number Supply Connection Rotor Connection Overall Length Housing Diameter Maximum Pressure and Media Speed
255-395-020 3/4"-14 NPT 3/4"-14 NPT RH 141.5 mm 5.571" 73.03 mm 2.875"

6.9 bar Hot Oil

5 bar Steam

51.7 bar Water

100 PSI Hot Oil

70 PSI Steam

750 PSI Water

1000 RPM
255-000-021044 3/4"-14 NPT 3/4"-14 NPT LH 171.45 mm 6.75" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

1500 RPM
255-052-273 3/4"-14 NPT 1/2"-14 NPT RH 136.525 mm 5.375" 75 mm 2.953"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

1500 RPM
255-052-445 3/4"-14 NPT G 3/4"-14 RH 136 mm 5.354" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

3500 RPM
255-352-035 3/4"-14 NPT 3/4"-14 NPT RH 152 mm 5.984" 79 mm 3.11"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

1500 RPM
255-381-898 1-1/16"-12 UN 1"-14 UNS RH, 31.7 mm pilot 1"-14 UNS RH, 1.248" pilot 161.5 mm 6.358" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

1500 RPM
255-011-219 3/4"-14 NPT 3/4"-14 NPT RH 147.6375 mm 5.813" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

1500 RPM
255-900-285981 3/4"-14 PT G 3/4"-14 LH 169.9 mm 6.689" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

3500 RPM
255-900-284075 3/4"-14 PT G 3/4"-14 RH 169.9 mm 6.689" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

3500 RPM
255-900-284981 3/4"-14 PT G 3/4"-14 RH 169.9 mm 6.689" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

3500 RPM
255-019-300 3/4"-14 NPT M22x1.5 LH, 26.993 mm pilot M22x1.5 LH, 1.063" pilot 133 mm 5.236" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

3500 RPM
255-000-003043 3/4"-14 NPT 1"-14 UNS RH 170.9 mm 6.728" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

3500 RPM
255-000-285 3/4"-14 NPT G 3/4"-14 LH 141 mm 5.551" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

3500 RPM
255-000-285043 3/4"-14 NPT G 3/4"-14 LH 171 mm 6.732" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

1500 RPM
255-019-470 3/4"-14 NPT M35x1.5 LH, 62 mm pilot M35x1.5 LH, 2.441" pilot 134 mm 5.276" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

3500 RPM
255-269-012 G 3/4"-14 M22x1.5 RH, 26.993 mm pilot M22x1.5 RH, 1.063" pilot 136.5 mm 5.374" 73.03 mm 2.875"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

3500 RPM
255-023-255 3/4"-14 NPT 3/4"-14 NPT RH 141.2748 mm 5.562" 72.9488 mm 2.872"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

1500 RPM
255-090-020 3/4"-14 NPT 3/4"-14 NPT RH 141 mm 5.551" 73.03 mm 2.875"

51.7 bar Water

750 PSI Water

1500 RPM
255-418-020 3/4"-14 NPT 3/4"-14 NPT RH 142.3 mm 5.602" 73.03 mm 2.875"

6.9 bar Hot Oil

6.9 bar Water

100 PSI Hot Oil

100 PSI Water

1500 RPM
255-401-014 3/4"-14 NPT M35x1.5 RH 131 mm 5.157" 73.03 mm 2.875"

10 bar Air

69 bar Hydraulic Oil

-0.95 bar Vacuum

150 PSI Air

1000 PSI Hydraulic Oil

-13.75 PSI Vacuum

3500 RPM
Page 1 of 5
