Product Selector

Many more designs are available. For assistance, contact Deublin Customer Service at +1-847-689-8660 or cs@deublin.com.

Imperial Metric
Filter By:

49 results out of 20,000+ available products.

Swipe for more
Deublin Part Number Supply Connection Rotor Connection Overall Length Housing Diameter Maximum Pressure and Media Speed
655-827-124 2"-11.5 NPT G 2"-11 RH 248 mm 9.764" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-921-421 G 1-1/4"-11 125 mm Flange, 80 mm pilot 4.921" Flange, 3.15" pilot 249 mm 9.803" 100 mm 3.937"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-500-117 2"-11.5 NPT 2"-11.5 NPT LH 253.5 mm 9.98" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-501-116 2"-11.5 NPT 2"-11.5 NPT RH 252 mm 9.921" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-634-116 2"-11.5 NPT 2"-11.5 NPT RH 256 mm 10.079" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-500-421 2"-11.5 NPT 125 mm Flange, 80 mm pilot 4.921" Flange, 3.15" pilot 253.5 mm 9.98" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-500-124 2"-11.5 NPT G 2"-11 RH 252.5 mm 9.941" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-912-226 2"-11.5 NPT Quick Connect, 65 mm pilot Quick Connect, 2.559" pilot 260.7 mm 10.264" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-500-125 2"-11.5 NPT G 2"-11 LH 248 mm 9.764" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-500-124177 2"-11.5 NPT G 2"-11 RH 306.5 mm 12.067" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-500-124221 2"-11.5 NPT G 2"-11 RH 289 mm 11.378" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

41 bar Water

100 PSI Hot Oil

15 PSI Steam

600 PSI Water

750 RPM
655-500-124208 2"-11.5 NPT G 2"-11 RH 312 mm 12.283" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-500-116 2"-11.5 NPT 2"-11.5 NPT RH 253.5 mm 9.98" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-086-850 2"-11.5 NPT G 2"-11 RH 246 mm 9.685" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-626-124 2"-11.5 NPT G 2"-11 RH 247 mm 9.724" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

5 bar Water/Glycol

100 PSI Hot Oil

15 PSI Steam

70 PSI Water/Glycol

750 RPM
655-500-124719 2"-11.5 NPT G 2"-11 RH 311 mm 12.244" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-900-198 2"-11 PT 2"-11 PT RH 259 mm 10.197" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-515-116 2"-11.5 NPT 2"-11.5 NPT RH 253.5 mm 9.98" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
655-527-125 G 2"-11 G 2"-11 LH 246 mm 9.685" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

41 bar Water

100 PSI Hot Oil

15 PSI Steam

600 PSI Water

750 RPM
655-527-124 G 2"-11 G 2"-11 RH 248 mm 9.764" 117.5 mm 4.626"

6.9 bar Hot Oil

1 bar Steam

13.8 bar Water

100 PSI Hot Oil

15 PSI Steam

200 PSI Water

750 RPM
Page 1 of 3
