Product Selector

Many more designs are available. For assistance, contact Deublin Customer Service at +1-847-689-8660 or cs@deublin.com.

Imperial Metric
Filter By:

32 results out of 20,000+ available products.

Swipe for more
Deublin Part Number Supply Connection Rotor Connection Overall Length Housing Diameter Maximum Pressure and Media Speed
755-1001 2-1/2"-8 NPT Quick Connect, 78.63 mm pilot Quick Connect, 3.096" pilot 469 mm 18.465" 178 mm 7.008"

6.9 bar Hot Oil

1 bar Steam

51.7 bar Water

100 PSI Hot Oil

15 PSI Steam

750 PSI Water

750 RPM
755-701-981117 2-1/2"-8 NPT 2-1/2"-8 NPT LH 381 mm 15" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-700-330 2-1/2"-8 NPT G 2-1/2"-11 RH 337 mm 13.268" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-701-413 2-1/2"-8 NPT 2-1/2"-8 NPT RH 319 mm 12.559" 177.8 mm 7"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-709-543 2-1/2"-8 NPT 304.8 mm Flange, 287.45 mm pilot 12" Flange, 11.317" pilot 394.5 mm 15.531" 203.2 mm 8"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-701-413117 2-1/2"-8 NPT 2-1/2"-8 NPT RH 381 mm 15" 177.8 mm 7"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-701-330 2-1/2"-8 NPT G 2-1/2"-11 RH 328.5 mm 12.933" 177.4 mm 6.984"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-706-413117 2-1/2"-8 NPT 2-1/2"-8 NPT RH 388.1374 mm 15.281" 177.8 mm 7"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-700-411 2-1/2"-8 NPT G 2-1/2"-11 LH 337 mm 13.268" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-708-413117 2-1/2"-8 NPT 2-1/2"-8 NPT RH 381 mm 15" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-700-330117 2-1/2"-8 NPT G 2-1/2"-11 RH 389 mm 15.315" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-702-415139 2-1/2"-8 NPT 2-1/2"-8 NPT LH 381 mm 15" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-700-415 2-1/2"-8 NPT 2-1/2"-8 NPT LH 336 mm 13.228" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-700-413117 2-1/2"-8 NPT 2-1/2"-8 NPT RH 393 mm 15.472" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-732-330139 G 2-1/2"-11 G 2-1/2"-11 RH 402 mm 15.827" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-759-330117 2-1/2"-8 NPT G 2-1/2"-11 RH 381 mm 15" 178.2 mm 7.016"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-746-911 2"-11.5 NPT 2-1/2"-8 NPT RH 339 mm 13.346" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-732-411139 G 2-1/2"-11 G 2-1/2"-11 LH 402 mm 15.827" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-708-330117 2-1/2"-8 NPT G 2-1/2"-11 RH 381 mm 15" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
755-700-411117 2-1/2"-8 NPT G 2-1/2"-11 LH 385 mm 15.157" 178 mm 7.008"

1 bar Steam

13.8 bar Water

15 PSI Steam

200 PSI Water

750 RPM
Page 1 of 2
