| Deublin Part Number | Supply Connection | Rotor Connection | Overall Length | Housing Diameter | Maximum Pressure and Media | Maximum Speed | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
1379-860 | G 3/8"-19 | 110 mm Flange, 60 mm pilot | 4.331" Flange, 2.362" pilot | 176 mm | 6.929" | 88 mm | 3.465" |
10 bar Air 60 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 870 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
|
1379-510 | 3/8"-18 NPT | 110 mm Flange, 60 mm pilot | 4.331" Flange, 2.362" pilot | 176 mm | 6.929" | 88 mm | 3.465" |
10 bar Air -0.95 bar Vacuum 6.9 bar Water |
150 PSI Air -13.75 PSI Vacuum 100 PSI Water |
50 RPM |
|
1379-460 | 3/8"-18 NPT | 110 mm Flange, 60 mm pilot | 4.331" Flange, 2.362" pilot | 176 mm | 6.929" | 88 mm | 3.465" |
10 bar Air 60 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 870 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
|
1379-160 | G 3/8"-19 | 110 mm Flange, 60 mm pilot | 4.331" Flange, 2.362" pilot | 176 mm | 6.929" | 88 mm | 3.465" |
10 bar Air 60 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 870 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
|
|
1379-160 | 110 mm Flange, 60 mm pilot | 4.331" Flange, 2.362" pilot | 88 mm | 3.465" |
10 bar Air 60 bar Hydraulic Oil -0.95 bar Vacuum |
150 PSI Air 870 PSI Hydraulic Oil -13.75 PSI Vacuum |
250 RPM |
