| Deublin Part Number | Supply Connection | Rotor Connection | Overall Length | Housing Diameter | Maximum Pressure and Media | Maximum Speed | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
357-000-002083 | 1"-11.5 NPT | 1"-11.5 NPT RH | 208 mm | 8.189" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
1500 RPM | |
|
357-000-235 | 1"-11.5 NPT | M35x1.5 RH | 157 mm | 6.181" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3000 RPM | |
|
|
357-045-578 | 1"-11 PT | 1"-11 PT LH | 174 mm | 6.85" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
1500 RPM | |
|
|
357-045-578 | 1"-11 PT LH | 1500 RPM | ||||||||
|
357-000-019 | 1"-11.5 NPT | 1-1/2"-12 UNF RH | 173 mm | 6.811" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3000 RPM | |
|
|
357-050-223 | 1"-11.5 NPT | G 1"-11 LH | 163 mm | 6.417" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3000 RPM | |
|
|
357-000-019083 | 1"-11.5 NPT | 1-1/2"-12 UNF RH | 207.7 mm | 8.177" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3000 RPM | |
|
|
357-051-198 | 1"-11.5 NPT | G 1"-11 RH | 163 mm | 6.417" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3000 RPM | |
|
|
357-051-198 | G 1"-11 RH | 3000 RPM | ||||||||
|
357-050-019 | 1"-11.5 NPT | 1-1/2"-12 UNF RH | 166.71 mm | 6.563" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | |
|
|
357-050-019 | 1-1/2"-12 UNF RH | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3500 RPM | ||||
|
|
357-000-222 | 1"-11.5 NPT | G 1"-11 RH | 167.5 mm | 6.594" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3000 RPM | |
|
357-000-223 | 1"-11.5 NPT | G 1"-11 LH | 164 mm | 6.457" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3000 RPM | |
|
|
357-000-002163 | 1"-11.5 NPT | 1"-11.5 NPT RH | 203 mm | 7.992" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
1500 RPM | |
|
357-045-222 | 1"-11.5 NPT | G 1"-11 RH | 6.934 mm | 0.273" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3000 RPM | |
|
357-130-222 | G 1"-11 | G 1"-11 RH | 166.5 mm | 6.555" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3000 RPM | |
|
357-000-003 | 1"-11.5 NPT | 1"-11.5 NPT LH | 173 mm | 6.811" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
1500 RPM | |
|
|
357-050-003083 | 1"-11.5 NPT | 1"-11.5 NPT LH | 208 mm | 8.189" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
1500 RPM | |
|
|
357-000-003083 | 1"-11.5 NPT | 1"-11.5 NPT LH | 208 mm | 8.189" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
1500 RPM | |
|
|
357-050-315 | 1"-11.5 NPT | M35x1.5 RH, 40 mm pilot | M35x1.5 RH, 1.575" pilot | 180 mm | 7.087" | 82.55 mm | 3.25" |
6.9 bar Hot Oil 1 bar Steam 51.7 bar Water |
100 PSI Hot Oil 15 PSI Steam 750 PSI Water |
3000 RPM |
