| Deublin Part Number | Supply Connection | Rotor Connection | Overall Length | Housing Diameter | Maximum Pressure and Media | Maximum Speed | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
6200-044-137 | 2"-11.5 NPT | G 2"-11 RH | 211.1 mm | 8.311" | 133.4 mm | 5.252" |
10 bar Water |
150 PSI Water |
750 RPM | |
|
|
6200-044-137 | G 2"-11 RH | 750 RPM | ||||||||
|
6200-001-137 | G 2"-11 RH | 290 mm | 11.417" | 133 mm | 5.236" |
10 bar Water |
150 PSI Water |
750 RPM | ||
|
|
6200-083-137 | 1"-11.5 NPT | G 2"-11 RH | 324.5 mm | 12.776" | 133.4 mm | 5.252" |
10 bar Water |
150 PSI Water |
750 RPM | |
|
|
6200-002-137 | 1"-11.5 NPT | G 2"-11 RH | 317 mm | 12.48" | 133 mm | 5.236" |
10 bar Water |
150 PSI Water |
750 RPM | |
|
|
6200-083-137 | G 2"-11 RH | 133.4 mm | 5.252" |
10 bar Water |
150 PSI Water |
750 RPM | ||||
|
|
6200-030-123 | 1"-11.5 NPT | 2"-11.5 NPT RH | 326 mm | 12.835" | 133.4 mm | 5.252" |
10 bar Water |
150 PSI Water |
750 RPM | |
|
|
6300-607-103 | 2"-11.5 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 499.4 mm | 19.661" | 228.6 mm | 9" |
10 bar Water |
150 PSI Water |
750 RPM |
|
|
6300-030-103 | 2"-11.5 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 499 mm | 19.646" | 229 mm | 9.016" |
10 bar Water |
150 PSI Water |
750 RPM |
|
|
6300-030-103 | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 229 mm | 9.016" |
10 bar Water |
150 PSI Water |
750 RPM | |||
|
|
6300-051-161 | 3"-8 NPT | G 3"-11 RH | 325 mm | 12.795" | 230 mm | 9.055" |
10 bar Water |
150 PSI Water |
750 RPM | |
|
|
6300-002-103 | 2"-11.5 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 505.5 mm | 19.902" | 229 mm | 9.016" |
10 bar Water |
150 PSI Water |
750 RPM |
|
|
6300-001-103 | 3"-8 NPT | 228.6 mm Flange, 101.7 mm pilot | 9" Flange, 4.004" pilot | 430 mm | 16.929" | 229 mm | 9.016" |
10 bar Water |
150 PSI Water |
750 RPM |
|
6400-115-330 | 4"-8 NPT | 276.2 mm Flange, 120.625 mm pilot | 10.874" Flange, 4.749" pilot | 348 mm | 13.701" | 278 mm | 10.945" |
10 bar Water |
150 PSI Water |
750 RPM |
|
6400-030-330 | 4"-8 NPT | 276.2 mm Flange, 120.62 mm pilot | 10.874" Flange, 4.749" pilot | 483 mm | 19.016" | 276 mm | 10.866" |
10 bar Water |
150 PSI Water |
750 RPM |
|
|
6400-115-330 | 276.2 mm Flange, 120.625 mm pilot | 10.874" Flange, 4.749" pilot | 278 mm | 10.945" |
10 bar Water |
150 PSI Water |
750 RPM | |||
|
|
6400-030-330 | 276.2 mm Flange, 120.62 mm pilot | 10.874" Flange, 4.749" pilot | 276 mm | 10.866" |
10 bar Water |
150 PSI Water |
750 RPM | |||
|
|
6400-042-330 | 4"-8 NPT | 276.2 mm Flange, 120.625 mm pilot | 10.874" Flange, 4.749" pilot | 490.5 mm | 19.311" | 276 mm | 10.866" |
10 bar Water |
150 PSI Water |
750 RPM |
|
|
6400-154-330 | 2-1/2"-8 NPT | 276.2 mm Flange, 120.625 mm pilot | 10.874" Flange, 4.749" pilot | 577 mm | 22.717" | 279 mm | 10.984" |
10 bar Water |
150 PSI Water |
750 RPM |
|
|
6400-031-330 | 2-1/2"-8 NPT | 276.2 mm Flange, 120.625 mm pilot | 10.874" Flange, 4.749" pilot | 550 mm | 21.654" | 279 mm | 10.984" |
10 bar Water |
150 PSI Water |
750 RPM |
